SEI-5K-H3P Mixed-Network Inverter
5kW | 3-Phase | 48Vdc
SEI-5K-H3P mixed-network inverter with 5,000W output rating. Three-phase 230/400Vac output, 48Vdc battery voltage, 120A max mixed charging current, and 5,000W+5,000W max PV input power.
Technical Specifications
- Model
- SEI-5K-H3P
- Output Rating
- 5,000W
- Output Voltage
- 230/400 Vac (three-phase)
- Max Peak Power
- 10,000VA
- Battery Voltage
- 48Vdc (40-60Vdc range)
- Max Mixed Charging
- 120A
- Max PV Input
- 5,000W + 5,000W
- Protection
- IP54
- Communication
- CAN / RS485 / USB / WIFI / Dry contact
- Warranty
- 5 years
IP65 Protection
10-Year Warranty
IATF 16949 Certified
